Fast. Reliable. Built for Busy Locations.
ExoBoost 120™ is designed for businesses, commercial centers, and high-traffic areas that need fast, steady, and repeatable charging every day.
It brings a strong balance of power, uptime, and efficiency, helping businesses attract drivers, increase customer dwell time, and earn new revenue from charging.
It works in places where electricity quality is not always perfect, where the weather gets hot, and where chargers must withstand long hours of use.
Designed for busy areas where EVs come and go all day:
• • shopping centers
• restaurants
• gas-station conversions
• taxi hubs
• fleet operators
• office complexes
• public charging corridors
ExoBoost 120™ keeps power stable even during peak hours, ensuring EV drivers always have a fast and dependable place to charge.
• 50 kWh EV → 20–28 minutes
• 60 kWh EV → 25–35 minutes
• 80 kWh EV → 35–45 minutes
These charging times make it easy for daily use quick top-ups, short stops, and overnight parking support.
ExoBoost 120™ continues charging even when the grid is:
Grid tolerance:
Liquid-cooled Electronics
Dust-proof Airflow Design
Reinforced Metal Enclosure
High-temperature Components
UV-resistant Coatings
Continuous Runtime:
Works 18–20 hours per day in high-temperature regions.
ExoBoost 120™ becomes even more powerful when paired with Exoben batteries:
Typical Storage Sizes:
Real-time intelligence built into every charger:
• Cloud-based monitoring
• Predictive maintenance
• Automated fault detection
• Dynamic load distribution
• RFID / QR / mobile app access
• Remote software updates
• Live performance dashboards
System refresh: updates every 200 milliseconds for accurate control.
• IP55–IP65 dust & water protection
• anti-tamper construction
• shock and vibration resistant
• reinforced metal housing
• designed for 10+ years of use
Perfect for outdoor commercial environments with constant foot traffic and heavy use.
| Category | Technical Details |
|---|---|
| Charging Power | 120 kW DC fast charging |
| Typical Charging Time (10–80%) | 12–35 minutes (50–100 kWh EVs) |
| Output Voltage | 150–1000V DC |
| Max Current | 50–600A |
| Efficiency | 96.5% |
| Input Requirements | 380–480V AC, 3-phase |
| Frequency | 50/60 Hz |
| Power Factor | ≥ 0.99 |
| THD | < 3% |
| Surge Protection | 10–40 kA |
| Operating Temperature | −20°C to +55°C |
| Cooling System | Liquid + forced-air hybrid cooling |
| Humidity Tolerance | 5–95% (non-condensing) |
| Enclosure Rating | IP55–IP65 |
| Semiconductor Technology | SiC / IGBT power modules |
| Switching Frequency | 20–60 kHz |
| Energy Storage Support | 5 kWh – 5 MWh |
| Connectivity | 4G/5G, Wi-Fi, Ethernet, RFID, QR, Mobile App |
| Protocols | OCPP 1.6 & 2.0.1 |
| Certifications | IEC 61851, IEC 62196, ISO 15118, CE, RoHS |
All specifications are subject to manufacturing tolerances and operating conditions. Contact our technical team for detailed integration requirements.
